Arda Flanges, a prominent manufacturer and supplier located in Istanbul, Turkey, is dedicated to crafting top-notch DIN 2527 PN10 Blind Flanges that are essential for reliable industrial piping systems. These flanges are specifically designed to ensure secure sealing and leak-proof performance in medium-pressure applications, all while adhering to the rigorous DIN 2527 standards. With a focus on precision and durability, the DIN 2527 PN10 Blind Flanges boast impressive corrosion resistance and mechanical strength, guaranteeing long-lasting performance even in challenging environments. Thanks to advanced manufacturing techniques, strict quality control, and a commitment to international standards, Arda Flanges has built a reputation as a trusted global supplier, catering to industries like chemical processing, water treatment, petrochemical, and general engineering.
Typically made from carbon steel, stainless steel, or alloy steel depending on the application, DIN 2527 PN10 Blind Flanges provide moderate to high tensile strength, yield strength, and elongation, making them suitable for medium-pressure systems. Their solid disc design effectively blocks flow and ensures reliable sealing. With excellent hardness, toughness, and corrosion resistance, these flanges deliver dependable mechanical performance and long-term durability, making them perfect for industrial piping applications where secure closure and resistance to wear and corrosion are crucial.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 95 | 14 | 65 | 4 | M 12 | 14 | 0,72 |
| 20 | 105 | 16 | 75 | 1,01 | |||
| 25 | 115 | 16 | 85 | 1,23 | |||
| 32 | 140 | 16 | 100 | M 16 | 18 | 1,8 | |
| 40 | 150 | 16 | 110 | 2,09 | |||
| 50 | 165 | 18 | 125 | 2,88 | |||
| 65 | 185 | 18 | 145 | 3,66 | |||
| 80 | 200 | 20 | 160 | 4,77 | |||
| 100 | 220 | 20 | 180 | 8 | 5,65 | ||
| 125 | 250 | 22 | 210 | 8,42 | |||
| 150 | 285 | 22 | 240 | M 20 | 22 | 10,4 | |
| 200 | 340 | 24 | 295 | 16,5 | |||
| 250 | 395 | 26 | 350 | 12 | 24 | ||
| 300 | 445 | 26 | 400 | 30,9 | |||
| 350 | 505 | 26 | 460 | 16 | 40,6 | ||
| 400 | 565 | 26 | 515 | M 24 | 26 | 49,4 | |
| 500 | 670 | 28 | 620 | 20 | 75 | ||
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of DIN 2527 PN10 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN10 Blind Flanges are widely utilized in industries that require secure pipeline closure under medium-pressure conditions. You’ll often find them in water supply and wastewater treatment systems, chemical and petrochemical plants, and general engineering pipelines. They’re also commonly used in HVAC systems, irrigation networks, and industrial process piping where reliable sealing is a must. Their robust design guarantees leak-proof performance, minimizes maintenance needs, and boosts operational safety. With their durability, corrosion resistance, and ease of installation, DIN 2527 PN10 Blind Flanges are a practical choice for any industrial piping application.
Yes, we offer custom sizes for DIN 2527 PN10 Blind Flanges to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2527 PN10 BLRF Flange Stockist in Turkey | Raised Faced DIN 2527 PN10 Slip-On flanges Dealer in İzmir |
| Nickel Alloy DIN 2527 PN10 Blind Flange | Mild Steel DIN 2527 PN10 Blind Flange |
| Stainless Steel DIN 2527 PN10 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 Blind FF Flange Supplier | Suppliers of DIN 2527 PN10 Blind Flange |
| DIN 2527 PN10 Blind Flange Dimensions | Raised Face DIN 2527 PN10 Blind Flange Manufacturer |
| 18 inch DIN 2527 PN10 Carbon Steel Blind Flange | DIN 2527 PN10 Blind Flange Dimensions in mm |
| Alloy Steel DIN 2527 PN10 Blind Flanges | Copper Nickel DIN 2527 PN10 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN10 Blind Pipe Flanges | DIN 2527 PN10 Blind Flanges Stockist |
| DIN 2527 PN10 BLRF Flange Exporter | DIN 2527 PN10 Blind Flange Pressure Ratings |
| Raised Face DIN 2527 PN10 Blind Plate Flanges | Titanium DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 Large Diameter Blind Flange | 30 Inch DIN 2527 PN10 Blind Pipe Flange Dimensions |
| 30 inch DIN 2527 PN10 Blind Flange Dealer | Raised Face DIN 2527 PN10 Blind Flanges Manufacturer |
| 4 inch Stainless Steel DIN 2527 PN10 Blind Flange | DIN 2527 PN10 Blind RF Flanges Stockholder |
| DIN 2527 PN10 Blind Flanges Supplier in Istanbul | MS DIN 2527 PN10 Blind Flange |
| ASME SA105N Raised Faced DIN 2527 PN10 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN10 Blind Flange |
| DIN 2527 PN10 Blind Flange Manufacturer | Flat Face DIN 2527 PN10 Blind Flange Manufacturer |
| DIN 2527 PN10 BLRF Flanges Distributor in Bursa | Flat Face DIN 2527 PN10 Blind Flanges Exporter |
| German Standard DIN 2527 PN10 Blind Flanges | DIN 2527 PN10 Blind Flange Supplier in Turkey |
| Carbon Steel DIN 2527 PN10 Blind Flange | DIN 2527 PN10 Blind RF Flange Supplier |
| Carbon Steel Raised Face DIN 2527 PN10 Blind Flange Stockist | Duplex Steel DIN 2527 PN10 BLRF Flanges Supplier in Istanbul |
| DIN 2527 PN10 Blind Pipe Flanges Supplier in West Istanbul | Duplex Steel DIN 2527 PN10 Blind Flanges |
| DIN 2527 PN10 BLRF Flanges Supplier in Bodrum | Alloy Steel DIN 2527 PN10 Blind Flanges Manufacturer in Turkey |
| DIN 2527 PN10 Blind Pipe Flanges Wholesaler | DIN 2527 PN10 BLRF Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
