Arda Flanges, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of DIN 2527 PN16 Blind Flanges, delivering high-quality solutions for piping systems that need secure closures. These flanges are expertly crafted to seal the ends of pipelines, pressure vessels, and equipment, ensuring leak-proof connections and maintaining system integrity. Built to meet DIN 2527 standards, PN16 Blind Flanges are perfect for medium-pressure applications, handling pressures up to 16 bar. With state-of-the-art production facilities, rigorous quality control, and a commitment to international standards, Arda Flanges guarantees durable, reliable, and cost-effective flange solutions for industrial applications around the globe.
Typically made from carbon steel, stainless steel, or alloy steel, DIN 2527 PN16 Blind Flanges boast impressive mechanical strength and resistance to corrosion. They offer high tensile and yield strength, making them suitable for medium-pressure applications, along with good toughness and dimensional stability. The solid, blind design effectively seals pipeline ends, preventing leaks and allowing for safe maintenance or modifications to the system. Their PN16 rating signifies a nominal pressure of 16 bar, making them versatile for a variety of industrial services.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 95 | 14 | 65 | 4 | M 12 | 14 | 0,72 |
| 20 | 105 | 16 | 75 | 1,01 | |||
| 25 | 115 | 16 | 85 | 1,23 | |||
| 32 | 140 | 16 | 100 | M 16 | 18 | 1,8 | |
| 40 | 150 | 16 | 110 | 2,09 | |||
| 50 | 165 | 18 | 125 | 2,88 | |||
| 65 | 185 | 18 | 145 | 3,66 | |||
| 80 | 200 | 20 | 160 | 8 | 4,77 | ||
| 100 | 220 | 20 | 180 | 5,65 | |||
| 125 | 250 | 22 | 210 | 8,42 | |||
| 150 | 285 | 22 | 240 | M 20 | 22 | 10,4 | |
| 200 | 340 | 24 | 295 | 12 | 16,1 | ||
| 250 | 405 | 26 | 355 | M 24 | 26 | 24,9 | |
| 300 | 460 | 28 | 410 | 35,1 | |||
| 350 | 520 | 30 | 470 | 16 | 47,8 | ||
| 400 | 580 | 32 | 525 | M 27 | 30 | 63,5 | |
| 500 | 715 | 36 | 650 | 20 | M 30 | 33 | 102 |
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of DIN 2527 PN16 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
You’ll find DIN 2527 PN16 Blind Flanges commonly used in industries like water treatment, chemical processing, petrochemical, oil and gas, and power generation. They’re ideal for closing off pipelines, pumps, valves, and pressure vessels where maintaining system integrity and preventing leaks is crucial. These flanges are frequently utilized in medium-pressure piping systems, industrial water networks, and chemical transfer lines. Thanks to their reliability, mechanical strength, and straightforward installation, DIN 2527 PN16 Blind Flanges offer a dependable solution for critical applications that demand safety, durability, and efficient pipeline management.
Yes, we offer custom sizes for DIN 2527 PN16 Blind Flanges to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Carbon Steel Raised Face DIN 2527 PN16 Blind Flange Stockist | Duplex Steel DIN 2527 PN16 BLRF Flanges Supplier in Istanbul |
| DIN 2527 PN16 Blind Pipe Flanges Supplier in Istanbul | Duplex Steel DIN 2527 PN16 Blind Flanges |
| DIN 2527 PN16 Blind FF Flange Supplier | Suppliers of DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Flange Dimensions | Raised Face DIN 2527 PN16 Blind Flange Manufacturer |
| Nickel Alloy DIN 2527 PN16 Blind Flange | Mild Steel DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Flange Manufacturer | Flat Face DIN 2527 PN16 Blind Flange Manufacturer |
| Stainless Steel DIN 2527 PN16 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN16 Blind Flanges |
| 18 inch DIN 2527 PN16 Carbon Steel Blind Flange | DIN 2527 PN16 Blind Flange Dimensions in mm |
| Alloy Steel DIN 2527 PN16 Blind Flanges | Copper Nickel DIN 2527 PN16 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN16 Blind Pipe Flanges | DIN 2527 PN16 Blind Flanges Stockist |
| DIN 2527 PN16 BLRF Flanges Distributor in Bursa | Flat Face DIN 2527 PN16 Blind Flanges Exporter |
| Raised Face DIN 2527 PN16 Blind Plate Flanges | Titanium DIN 2527 PN16 Blind Flanges |
| DIN 2527 PN16 Large Diameter Blind Flange | 30 Inch DIN 2527 PN16 Blind Pipe Flange Dimensions |
| 30 inch DIN 2527 PN16 Blind Flange Dealer | Raised Face DIN 2527 PN16 Blind Flanges Manufacturer |
| ASME SA105N Raised Faced DIN 2527 PN16 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN16 Blind Flange |
| German Standard DIN 2527 PN16 Blind Flanges | DIN 2527 PN16 Blind Flange Supplier in İzmir |
| Carbon Steel DIN 2527 PN16 Blind Flange | DIN 2527 PN16 Blind RF Flange Supplier |
| 4 inch Stainless Steel DIN 2527 PN16 Blind Flange | DIN 2527 PN16 Blind RF Flanges Stockholder |
| DIN 2527 PN16 Blind Flanges Supplier in West Istanbul | MS DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Pipe Flanges Wholesaler | DIN 2527 PN16 BLRF Flanges Supplier |
| DIN 2527 PN16 BLRF Flanges Supplier in Bodrum | Alloy Steel DIN 2527 PN16 Blind Flanges Manufacturer in Turkey |
| DIN 2527 PN16 BLRF Flange Exporter | DIN 2527 PN16 Blind Flange Pressure Ratings |
| DIN 2527 PN16 BLRF Flange Stockist in Turkey | Raised Faced DIN 2527 PN16 Slip-On flanges Dealer in Turkey |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
