Arda Flanges, a prominent manufacturer and supplier located in Istanbul, Turkey, is dedicated to crafting top-notch DIN 2527 PN6 Blind Flanges for industrial piping systems. These flanges are designed to deliver dependable sealing solutions, ensuring a leak-proof performance even in low-pressure situations. Built in accordance with DIN 2527 standards, the PN6 Blind Flanges boast durability, precision, and resistance to corrosion, making them perfect for a variety of industrial settings. Thanks to their state-of-the-art production facilities, rigorous quality control, and commitment to international standards, Arda Flanges has earned a reputation as a reliable global supplier of DIN 2527 PN6 Blind Flanges, catering to industries like water treatment, chemical processing, and general engineering around the world.
Typically crafted from carbon steel, stainless steel, or alloy steel based on specific application needs, DIN 2527 PN6 Blind Flanges provide moderate tensile strength, yield strength, and elongation that are well-suited for low-pressure systems. Their solid disc design effectively halts pipeline flow, ensuring a secure seal. With impressive hardness, toughness, and corrosion resistance, these flanges guarantee reliable mechanical performance and long-lasting durability, making them an excellent choice for low-pressure industrial piping applications.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 80 | 12 | 55 | 4 | M 10 | 11 | 0.44 |
| 20 | 90 | 14 | 65 | 0.66 | |||
| 25 | 100 | 14 | 75 | 0.83 | |||
| 32 | 120 | 14 | 90 | M 12 | 14 | 1.18 | |
| 40 | 130 | 14 | 100 | 1.39 | |||
| 50 | 140 | 14 | 110 | 1.63 | |||
| 65 | 160 | 14 | 130 | 2.15 | |||
| 80 | 190 | 16 | 150 | M 16 | 18 | 3.44 | |
| 100 | 210 | 16 | 170 | 4.22 | |||
| 125 | 240 | 18 | 200 | 8 | 6.11 | ||
| 150 | 265 | 18 | 225 | 7.51 | |||
| 200 | 320 | 20 | 280 | 12.31 | |||
| 250 | 375 | 22 | 335 | 12 | 18.54 | ||
| 300 | 440 | 22 | 395 | M 20 | 22 | 25.46 | |
| 350 | 490 | 22 | 445 | 31.77 | |||
| 400 | 540 | 22 | 495 | 16 | 38.49 | ||
| 500 | 645 | 24 | 600 | 20 | 60.10 | ||
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of DIN 2527 PN6 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN6 Blind Flanges are extensively utilized in sectors that demand secure and leak-proof sealing solutions. They’re commonly found in water supply networks, wastewater treatment facilities, and chemical processing systems, where they safely block or isolate sections of pipelines. Additionally, these flanges are ideal for HVAC systems, irrigation pipelines, and general engineering applications that require low-pressure sealing. Their robust design ensures dependable performance, minimizes maintenance needs, and enhances operational safety. With their durability and resistance to corrosion, DIN 2527 PN6 Blind Flanges are a practical and efficient option for low-pressure industrial piping systems across the globe.
Yes, we offer custom sizes for DIN 2527 PN6 Blind Flanges to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2527 PN6 BLRF Flanges Supplier in Istanbul | Alloy Steel DIN 2527 PN6 Blind Flanges Manufacturer in Turkey |
| DIN 2527 PN6 Blind Flange Dimensions | Raised Face DIN 2527 PN6 Blind Flange Manufacturer |
| 18 inch DIN 2527 PN6 Carbon Steel Blind Flange | DIN 2527 PN6 Blind Flange Dimensions in mm |
| Stainless Steel DIN 2527 PN6 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN6 Blind Flanges |
| DIN 2527 PN6 Blind FF Flange Supplier | Suppliers of DIN 2527 PN6 Blind Flange |
| Alloy Steel DIN 2527 PN6 Blind Flanges | Copper Nickel DIN 2527 PN6 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN6 Blind Pipe Flanges | DIN 2527 PN6 Blind Flanges Stockist |
| DIN 2527 PN6 BLRF Flange Stockist in Turkey | Raised Faced DIN 2527 PN6 Slip-On flanges Dealer in İzmir |
| Nickel Alloy DIN 2527 PN6 Blind Flange | Mild Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 BLRF Flange Exporter | DIN 2527 PN6 Blind Flange Pressure Ratings |
| Raised Face DIN 2527 PN6 Blind Plate Flanges | Titanium DIN 2527 PN6 Blind Flanges |
| 30 inch DIN 2527 PN6 Blind Flange Dealer | Raised Face DIN 2527 PN6 Blind Flanges Manufacturer |
| DIN 2527 PN6 Large Diameter Blind Flange | 30 Inch DIN 2527 PN6 Blind Pipe Flange Dimensions |
| 4 inch Stainless Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flanges Stockholder |
| DIN 2527 PN6 Blind Flanges Supplier in Bursa | MS DIN 2527 PN6 Blind Flange |
| Carbon Steel Raised Face DIN 2527 PN6 Blind Flange Stockist | Duplex Steel DIN 2527 PN6 BLRF Flanges Supplier in Antalya |
| DIN 2527 PN6 Blind Pipe Flanges Wholesaler | DIN 2527 PN6 BLRF Flanges Supplier |
| DIN 2527 PN6 Blind Flange Manufacturer | Flat Face DIN 2527 PN6 Blind Flange Manufacturer |
| DIN 2527 PN6 BLRF Flanges Distributor in Turkey | Flat Face DIN 2527 PN6 Blind Flanges Exporter |
| German Standard DIN 2527 PN6 Blind Flanges | DIN 2527 PN6 Blind Flange Supplier in Turkey |
| ASME SA105N Raised Faced DIN 2527 PN6 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN6 Blind Flange |
| DIN 2527 PN6 Blind Pipe Flanges Supplier in West Istanbul | Duplex Steel DIN 2527 PN6 Blind Flanges |
| Carbon Steel DIN 2527 PN6 Blind Flange | DIN 2527 PN6 Blind RF Flange Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
