Arda Flanges, based in Istanbul, Turkey, is a reliable manufacturer and supplier of DIN 2565 PN6 Threaded Flanges. These flanges are perfect for low-pressure piping systems where welding just isn’t an option. With internal threads, they can be easily screwed onto a pipe, ensuring a secure and leak-proof connection without the hassle of welding. Built to meet DIN 2565 standards and rated for PN6 pressure, they can handle applications up to 6 bar. Thanks to their modern production facilities, rigorous quality control, and adherence to international standards, Arda Flanges delivers durable, safe, and cost-effective flange solutions for various industrial needs.
Typically crafted from carbon steel, stainless steel, or alloy steel, DIN 2565 PN6 Threaded Flanges offer the mechanical strength, corrosion resistance, and precise dimensions required for low-pressure service. They provide adequate tensile and yield strength for PN6-rated systems, along with impressive toughness and ductility. The threaded design allows for quick installation and removal, making them a great choice for piping systems where welding isn’t practical or where maintenance happens frequently. Their PN6 rating means they’re reliable for pressures up to 6 bar, making them a solid option for low-pressure pipelines.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 80 | 12 | 55 | 20 | 30 | 40 | 2 | 4 | M 10 | 11 | 0,373 |
| 20 | 26,9 | R 3/4 | 90 | 14 | 65 | 24 | 40 | 50 | 2 | 4 | M 10 | 11 | 0,59 |
| 25 | 33,7 | R 1 | 100 | 14 | 75 | 24 | 50 | 60 | 2 | 4 | M 10 | 11 | 0,743 |
| 32 | 42,4 | R 1 1/4 | 120 | 14 | 90 | 26 | 60 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 40 | 48,3 | R 1 1/2 | 130 | 14 | 100 | 26 | 70 | 80 | 3 | 4 | M 12 | 14 | 1,2 |
| 50 | 60,3 | R 2 | 140 | 14 | 110 | 28 | 80 | 90 | 3 | 4 | M 12 | 14 | 1,37 |
| 65 | 76,1 | R 2 1/2 | 160 | 14 | 130 | 32 | 100 | 110 | 3 | 4 | M 12 | 14 | 1,92 |
| 80 | 88,9 | R 3 | 190 | 16 | 150 | 34 | 110 | 128 | 3 | 4 | M 16 | 18 | 2,82 |
| 100 | 114,3 | R 4 | 210 | 16 | 170 | 38 | 130 | 148 | 3 | 4 | M 16 | 18 | 3,19 |
| 125 | 139,7 | R 5 | 240 | 18 | 200 | 40 | 160 | 178 | 3 | 8 | M 16 | 18 | 4,47 |
| 150 | 165,1 | R 6 | 265 | 18 | 225 | 44 | 185 | 202 | 3 | 8 | M 16 | 18 | 5,3 |
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of DIN 2565 PN6 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
You’ll find DIN 2565 PN6 Threaded Flanges used in a variety of settings, including water treatment, chemical processing, HVAC systems, and other industrial applications. They’re ideal for connecting pipelines, pumps, valves, and pressure vessels where welding isn’t feasible or preferred. Commonly found in industrial fluid transfer lines, low-pressure chemical pipelines, and water distribution systems, these flanges offer ease of installation, mechanical reliability, and resistance to corrosion, making them an efficient, durable, and safe choice for low-pressure industrial piping systems.
Yes, we offer custom sizes for DIN 2565 PN6 Threaded Flanges to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| DIN 2565 PN6 Threaded Flanges Supplier in Istanbul | Alloy Steel DIN 2565 PN6 Threaded Flanges Manufacturer in Turkey |
| DIN 2565 PN6 Screwed Flange Stockist in Turkey | Raised Faced DIN 2565 PN6 Slip-On flanges Dealer in İzmir |
| ASME SA105N Raised Faced DIN 2565 PN6 Threaded Flanges | 18 inch Carbon Steel DIN 2565 PN6 Threaded Flange |
| Stainless Steel DIN 2565 PN6 Threaded Flange | ASTM B564 Raised Faced DIN 2565 PN6 Threaded Flanges |
| Carbon Steel Raised Face DIN 2565 PN6 Screwed Flange Stockist | Duplex Steel DIN 2565 PN6 Threaded Flanges Supplier in mm |
| DIN 2565 PN6 Threaded Flange Dimensions | Raised Face DIN 2565 PN6 Threaded Flange Manufacturer |
| Carbon Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Threaded RF Flange Supplier |
| DIN 2565 PN6 Threaded Flanges Distributor in Bursa | Flat Face DIN 2565 PN6 Threaded Flanges Exporter |
| DIN 2565 PN6 Threaded Flange Manufacturer | Flat Face DIN 2565 PN6 Screwed Flange Manufacturer |
| 30 inch DIN 2565 PN6 Threaded Flange Dealer | Raised Face DIN 2565 PN6 Threaded Flanges Manufacturer |
| 18 inch DIN 2565 PN6 Carbon Steel Threaded Flange | DIN 2565 PN6 Threaded Flange Dimensions in mm |
| 8 Inch DIN 2565 PN6 Threaded Pipe Flanges | DIN 2565 PN6 Threaded Flanges Stockist |
| Alloy Steel DIN 2565 PN6 Threaded Flanges | Copper Nickel DIN 2565 PN6 Threaded Flanges at Best Price |
| Nickel Alloy DIN 2565 PN6 Threaded Flange | Mild Steel DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Screwed Flanges Supplier in West Istanbul | MS DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Flange Exporter | DIN 2565 PN6 Threaded Flange Pressure Ratings |
| DIN 2565 PN6 Large Diameter Threaded Flange | 30 Inch DIN 2565 PN6 Threaded Pipe Flange Dimensions |
| Raised Face DIN 2565 PN6 Threaded Plate Flanges | Titanium DIN 2565 PN6 Threaded Flanges |
| 4 inch Stainless Steel DIN 2565 PN6 Threaded Flange | DIN 2565 PN6 Screwed RF Flanges Stockholder |
| DIN 2565 PN6 Threaded FF Flange Supplier | Suppliers of DIN 2565 PN6 Threaded Flange |
| DIN 2565 PN6 Threaded Pipe Flanges Supplier in Bodrum | Duplex Steel DIN 2565 PN6 Threaded Flanges |
| German Standard DIN 2565 PN6 Threaded Flanges | DIN 2565 PN6 Threaded Flange Supplier in Turkey |
| DIN 2565 PN6 Threaded Pipe Flanges Wholesaler | DIN 2565 PN6 Threaded Flanges Supplier |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
