Arda Flanges, a reputable manufacturer and supplier located in Istanbul, Turkey, focuses on crafting top-notch DIN 2566 PN16 Threaded Flanges for industrial piping systems. These flanges are designed to create secure, leak-proof connections without the hassle of welding, making them perfect for medium-pressure applications where easy installation and maintenance are key. Built to meet DIN 2566 standards, the PN16 Threaded Flanges boast durability, resistance to corrosion, and precise dimensional accuracy. Thanks to their state-of-the-art production facilities and strict quality control measures, Arda Flanges has earned a solid reputation as a dependable global supplier, catering to industries like chemical, petrochemical, water treatment, and general engineering.
Typically, DIN 2566 PN16 Threaded Flanges are crafted from carbon steel, stainless steel, or alloy steel, depending on the specific application needs. They come with internal threads that allow for direct screwing onto pipes, eliminating the need for welding altogether. These flanges offer moderate tensile strength, yield strength, and elongation, making them suitable for medium-pressure operations. With impressive hardness, toughness, and corrosion resistance, DIN 2566 PN16 Threaded Flanges guarantee reliable mechanical performance, durability, and long-lasting service across various industrial piping systems.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 95 | 14 | 65 | 20 | 35 | 45 | 2 | 4 | M 12 | 14 | 0,613 |
| 20 | 26,9 | R 3/4 | 105 | 16 | 75 | 24 | 45 | 58 | 2 | 4 | M 12 | 14 | 0,91 |
| 25 | 33,7 | R 1 | 115 | 16 | 85 | 24 | 52 | 68 | 2 | 4 | M 12 | 14 | 1,1 |
| 32 | 42,4 | R 1 1/4 | 140 | 16 | 100 | 26 | 60 | 78 | 2 | 4 | M 16 | 18 | 1,6 |
| 40 | 48,3 | R 1 1/2 | 150 | 16 | 110 | 26 | 70 | 88 | 3 | 4 | M 16 | 18 | 1,78 |
| 50 | 60,3 | R 2 | 165 | 18 | 125 | 28 | 85 | 102 | 3 | 4 | M 16 | 18 | 2,43 |
| 65 | 76,1 | R 2 1/2 | 185 | 18 | 145 | 32 | 105 | 122 | 3 | 4 | M 16 | 18 | 3,18 |
| 80 | 88,9 | R 3 | 200 | 20 | 160 | 34 | 118 | 138 | 3 | 8 | M 16 | 18 | 4,12 |
| 100 | 114,3 | R 4 | 220 | 20 | 180 | 38 | 140 | 158 | 3 | 8 | M 16 | 18 | 4,47 |
| 125 | 139,7 | R 5 | 250 | 22 | 210 | 40 | 168 | 188 | 3 | 8 | M 16 | 18 | 6,13 |
| 150 | 165,1 | R 6 | 285 | 22 | 240 | 44 | 195 | 212 | 3 | 8 | M 20 | 22 | 7,92 |
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of DIN 2566 PN16 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
You’ll find DIN 2566 PN16 Threaded Flanges widely used in sectors where welding is either challenging or not preferred. They’re commonly found in chemical and petrochemical plants, water treatment systems, and oil and gas pipelines that require medium-pressure connections. HVAC systems, low-pressure steam lines, and general industrial process piping also benefit from threaded flanges due to their ease of assembly and disassembly. Their screw-on design ensures leak-proof joints, cuts down installation time, and simplifies maintenance or replacement. With their corrosion resistance, mechanical stability, and operational safety, DIN 2566 PN16 Threaded Flanges are an excellent choice for medium-pressure applications.
Yes, we offer custom sizes for DIN 2566 PN16 Threaded Flanges to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
