Arda Flanges, a well-respected manufacturer and supplier located in Istanbul, Turkey, specializes in providing top-notch flange solutions that adhere to international standards. Among their offerings, the St37-2 Flanges are crafted for dependable, cost-effective connections in various industrial piping systems. Renowned for their strength and durability, these carbon steel flanges create secure joints for pipelines, valves, and equipment. Arda’s St37-2 Flanges are meticulously engineered to facilitate easy installation and ensure long-lasting performance, making them a go-to choice for industries that need to handle moderate pressure and standard carbon steel flange solutions.
St37-2 Flanges are made from mild carbon steel, typically containing 0.17–0.20% carbon, 0.40–0.65% manganese, along with small amounts of sulfur and phosphorus. This blend gives them good tensile strength, yield strength, and moderate ductility, making these flanges perfect for general industrial applications. They also show decent toughness and fatigue resistance under normal operating conditions. With their excellent weldability and formability, St37-2 Flanges are well-suited for moderate-pressure applications, ensuring reliable performance in standard industrial settings.
Arda Flanges, a leading supplier in Istanbul, Turkey, offers an extensive selection of St37-2 Flange, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | API7S-15, API7S-43, API605, ANSI/ASME B16.5, B16.47 Series A & B, B16.48, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, EN1092 |
| Pressure Rating ANSI | 600 LBS, 900 LBS, 150 LBS, 2500 LBS, 300 LBS, 1500 LBS |
| Pressure Calculation in DIN | 16Bar 6Bar 25Bar 40Bar 10Bar / PN10 PN16 PN6 PN25 PN64 PN40 |
| JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Anti-rust Paint, Zinc Plated,Oil Black Paint, Cold and Hot Dip Galvanized, Yellow Transparent |
| Most common types | Forged / Threaded / Screwed / Plate |
| Steel grade | Styles | Carbon, max, % | Silicon, % | Manganese, % | Phosphorus, max, % | Sulfur, max, % | Nitrogen, max, % |
| ST37-2 | Steel Angles | 0.20 | 0.15 – 0.35 | 0.35 – 0.75 | 0.050 | 0.050 | 0.011 |
| Steel grade | Styles | Tensile strength, ksi [MPa] | Yield point, min, ksi [MPa] | Elongation, min, δ, % |
| ST37-2 | Steel Angles | 52 – 67 [360 – 460] | 34 [235] | 25 |
St37-2 Flanges find their place in various industries that need durable, cost-effective carbon steel connections. They are frequently used in water supply systems, general industrial piping, HVAC installations, and structural projects. These flanges are ideal for low to moderate-pressure applications, providing secure and dependable connections for valves, pipes, and equipment. Additionally, St37-2 Flanges are utilized in fabrication, construction, and general engineering projects where standard carbon steel materials are adequate. They promote operational efficiency, ease of installation, and a long service life in typical industrial environments.
Yes, we offer custom sizes for St37-2 Flange to meet specific project needs. Our team at Arda Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@ardaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
